·PC based
·Full digital imaging technology
·10 inch LCD screen(SS-10B)
·Silica gel control panel
·Broadband Multi-frequency probes
·512/1024 frame cine loop
·8 segment TGC
·16 step zoom
·140 body marks
·Powerful information management
·Complete application software packages
·1GB permanent storage
·USB ports
·Compatible with laser/inkjet printers

Specification:

-D-Maximum Scanning Depth： 250mm
-Multi-frequency: 5 segment frequencies
-Zoom: 10 ratio, 1.5, 2.0, 2.5, 3.0, 3.5, 4.0, 4.5, 5.0, 5.5, 6.0
-Image gray scale: 256 level gray scale
-Cine Loop：1024 frames
-Scanning mode: B, 2B, B/M, M, 4B, ZOOM;
 Real-time Zoom on B mode
-Image processing: Pre-processing, after-processing, dynamic range, frame rate, line average, edge; enhancement, Black/White inversion; Gray scale adjustment,  contrast, brightness, γ revision.
-Gain: gain: adjustable between 0-100dB; Time gain control(TGC): 8 segment adjustment, B, M adjustment separately.
-Monitor: 12 inch high definition LCD screen(SS-10A) or 10 inch LCD screen(SS-10B)
-Supported output apparatus: U-Disk, Laser/ink printer, video printer, VGA
-Measurement and calculation(veterinary):
  Cattle: BPD, CRL, TD;  Horse: GA; Dog: GS; Cat: HD, BD; Sheep: BPD, CRL, TD
-Dimension: 300×230×85mm
-Probe Connector：2
-Weight: Around 2.3kg
